AMD CPU Series

AM4/5

AMD AM4/5 Series

CS-AM4/5-1U1CA-P

Vapor chamber

CPU Socket: AMD® AM4/5
Passive cooler
Dimensions: 78*104*24.5mm
Fin thickness: 0.3mm
Fin spacing: 1.73mm
TDP: 120W
Material: VC base + copper fins + 4 heat pipes

CS-AM4/5-1U3C

CPU Socket: AMD® AM4/5
Voltage: 12V
Dimensions: 104*80*28.5mm
Fan Speed: 1500-6000 ± 10% RPM
Fan Noise: 64.0 dBA (Max)
Fan Airflow: 21.35 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 105W
Material: copper fins

CS-AM4-1UP31
Coolserver AM4 cooler, TDP: 95W

CS-AM4/5-1UP31

CPU Socket: AMD® AM4/5
Voltage: 12V
Dimensions: 104*70*27.5mm
Fan Speed: 2000-5000 ± 10% RPM
Fan Noise: 54.8 dBA (Max)
Fan Airflow: 10.37 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 95W
Material: copper fins

CS-AM4-1UP32
Coolserver AM4 Cooler, TDP: 110W

CS-AM4/5-1UP32

CPU Socket: AMD® AM4/5
Voltage: 12V
Dimensions: 104*80*27.5mm
Fan Speed: 1500-6600 ± 10% RPM
Fan Noise: 64.0 dBA (Max)
Fan Airflow:21.35 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 110W
Material: copper fins

CS-AM4-2UM62-P
Coolserver AM4 passive cooler, TDP: 110W

CS-AM4/5-2UM62-P

CPU Socket: AMD® AM4/5
Passive cooler
Dimensions: 110*78*64.5mm
Fin thickness: 0.4mm
Fin spacing: 2.18mm
TDP: 145W
Material: Alu base + Alu fins + 3 heat pipes

CS-AM4/5-2UM61P

CPU Socket: AMD® AM4/5
Passive cooler
Dimensions: 103*90*65mm
Fin thickness: 0.4mm
Fin spacing: 2.18mm
TDP: 130W
Material: Alu base + Alu fins + 2 heat pipes

CS-AM4-2UR63
Coolserver AM4 cooler, TDP: 150W

CS-AM4/5-2UR63

CPU Socket: AMD® AM4/5
Voltage: 12V
Dimensions: 99*82.7*67mm
Fan Speed: 2100-6800 ± 10% RPM
Fan Noise: 52.0 dBA (Max)
Fan Airflow: 34.5 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 150W
Material: Alu fins + 4 heat pipes

CS-AM4/5-2UR64

CPU Socket: AMD® AM4/5
Voltage: 12V
Dimensions: 99*85.2*67mm
Fan Speed: 2100-6800 ± 10% RPM
Fan Noise: 52.0 dBA (Max)
Fan Airflow: 34.5 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 160W
Material: Alu fins + 4 heat pipes

CS-AM4/5-2UR65

CPU Socket: AMD® AM4/5
Voltage: 12V
Dimensions: 99*85.2*67.7mm
Fan Speed: 2600-8000 ± 10% RPM
Fan Noise: 52.5 dBA (Max)
Fan Airflow: 47.2 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 165W
Material: Alu fins + 5 heat pipes

CS-AM4/5-2UR65-T

CPU Socket: AMD® AM4/5
Voltage: 12V
Dimensions: 99*85.3*67.7mm
Fan Speed: 2600-8000 ± 10% RPM
Fan Noise: 52.5 dBA (Max)
Fan Airflow: 47.2 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 165W
Material: Alu fins + 5 heat pipes

CS-AM4/5-2UR67

CPU Socket: AMD® AM4/5
Voltage: 12V
Dimensions: 100*90*67.5mm
Fan Speed: 3000-11000 ± 10% RPM
Fan Noise: 58.5 dBA (Max)
Fan Airflow: 62 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 200W
Material: Alu fins + 5 heat pipes

CS-AM4-2U6CA
Coolserver AM4 Cooler, TDP: 95W

CS-AM4/5-2U6CA

CPU Socket: AMD® AM4/5
Voltage: 12V
Dimensions: 104*75*67mm
Fan Speed: 2100-6800 ± 10% RPM
Fan Noise: 52.0 dBA (Max)
Fan Airflow: 34.5 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 125W
Material: Cu base + Alu fins

CS-AM4-2U6C
Coolserver AM4 cooler, TDP: 95W

CS-AM4/5-2U6C

CPU Socket: AMD® AM4/5
Voltage: 12V
Dimensions: 104*75*67mm
Fan Speed: 2100-6800 ± 10% RPM
Fan Noise: 52.0 dBA (Max)
Fan Airflow: 34.5 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 135W
Material: Cu base + Alu fins

CS-AM4/5-M87

CPU Socket: AMD® AM4/5
Voltage: 12V
Dimensions: 106*78*64.5mm
Fan Speed: 3000-11000 ± 10% RPM
Fan Noise: 58.5 dBA (Max)
Fan Airflow: 62.0 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 185W
Material: Alu fins + 5 heat pipes

CS-AM4/5-M88

CPU Socket: AMD® AM4/5
Voltage: 12V
Dimensions: 106*78*67mm
Fan Speed: 3000-11000 ± 10% RPM
Fan Noise: 58.5 dBA (Max)
Fan Airflow: 62.0 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 200W
Material: Alu fins + 5 heat pipes

CS-AM4-4UR22
Coolserver AM4 cooler, TDP: 200W

CS-AM4/5-4UR22

CPU Socket: AMD® AM4/5
Voltage: 12V
Dimensions: 98.8*100*124.8mm
Fan Speed: 1900-3800 ± 10% RPM
Fan Noise: 44.0 dBA (Max)
Fan Airflow: 61.46 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 180W
Material: Alu fins + 5 heat pipes

CS-AM4/5-4UR22-T

CPU Socket: AMD® AM4/5
Voltage: 12V
Dimensions: 103.7*92.5*124.6mm
Fan Speed: 1900-3800 ± 10% RPM
Fan Noise: 44.0 dBA (Max)
Fan Airflow: 61.46 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 180W
Material: Alu fins + 5 heat pipes

CS-AM4/5-4UR22-T

CPU Socket: AMD® AM4/5
Voltage: 12V
Dimensions: 107.6*70.6*126.2mm
Fan Speed: 2000-5000 ± 10% RPM
Fan Noise: 45.0 dBA (Max)
Fan Airflow: 128 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 210W
Material: Cu base + Alu fins + 5 heat pipes

CS-AM4/5-4UR22-T

CPU Socket: AMD® AM4/5
Voltage: 12V
Dimensions: 107.6*90*126.2mm
Fan Speed: 2000-5000 ± 10% RPM
Fan Noise: 45.0 dBA (Max)
Fan Airflow: 128 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 210W
Material: Cu base + Alu fins + 5 heat pipes

CS-AM4/5-4UR22-T

CPU Socket: AMD® AM4/5
Voltage: 12V
Dimensions: 130*106*151mm
Fan Speed: 1000-2200 ± 10% RPM
Fan Noise: 36.0 dBA (Max)
Fan Airflow: 72.68 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 220W
Material: Cu base + Alu fins + 6 heat pipes

SP3/ TR4

AMD SP3/TR4 series

CS-SP3-1UP11-P
Coolserver SP3 cooler, TDP: 180W

CS-SP3-1UP11-P

CPU Socket: AMD® SP3/TR4
Passive cooler
Dimensions: 120*80*26mm
Fin thickness: 0.3mm
Fin spacing: 1.5mm
TDP: 180W
Material: Cu base + Alu fins + 4 heat pipes

CS-SP3-2UP21-P
Coolserver SP3 cooler, TDP: 110W

CS-SP3-2UP21-P

CPU Socket: AMD® SP3/TR4
Passive cooler
Dimensions: 117*78.9*64mm
Fin thickness: 0.4mm
Fin spacing: 2.24mm
TDP: 260W
Material: Cu base + Alu fins + 4 heat pipes

CS-SP3-2UP22
Coolserver SP3 cooler, TDP: 200W

CS-SP3-2UP22

CPU Socket: AMD® SP3/TR4
Voltage: 12V
Dimensions: 119.3*78.9*64.5mm
Fan Speed: 1900-3800 ± 10% RPM
Fan Noise: 52.0 dBA (Max)
Fan Airflow: 34.74 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 260W
Material: Alu fins + 4 heat pipes

CS-SP3-2UP23
Coolserver SP3 cooler, TDP: 320W

CS-SP3-2UP23

CPU Socket: AMD® SP3/TR4
Voltage: 12V
Dimensions: 115*78*66.3mm
Fan Speed: 2600-8000 ± 10% RPM
Fan Noise: 52.5 dBA (Max)
Fan Airflow: 47.2 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 320W
Material: Alu fins + 5 heat pipes

CS-SP3-2US87

CPU Socket: AMD® SP3/TR4
Voltage: 12V
Dimensions:118*79*64.5mm
Fan Speed: 3000-11000 ± 10% RPM
Fan Noise: 58.5 dBA (Max)
Fan Airflow: 62.0 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 350W
Material: Cu base + Alu fins + 5 heat pipes

CS-SP3-4UP41
Coolserver SP3 cooler, TDP: 280W

CS-SP3-4UP41

CPU Socket: AMD® SP3/TR4
Voltage: 12V
Dimensions: 120*92*125.4mm
Fan Speed: 1900-3800 ± 10% RPM
Fan Noise: 44.0 dBA (Max)
Fan Airflow: 61.46 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 280W
Material: Alu fins + 5 heat pipes

CS-SP3-4UP42
Coolserver SP3 cooler, TDP: 300W

CS-SP3-4UP42

CPU Socket: AMD® SP3/TR4
Voltage: 12V
Dimensions: 120*92.5*125.4mm
Fan Speed: 1900-3800 ± 10% RPM
Fan Noise: 44.0 dBA (Max)
Fan Airflow: 61.46 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 300W
Material: Cu base + Alu fins + 6 heat pipes

CS-SP3-4UM95
Coolserver SP3 cooler, TDP: 360W

CS-SP3-4UM95

CPU Socket: AMD® SP3/TR4
Voltage: 12V
Dimensions: 118*103*124.5mm
Fan Speed: 1500-3800 ± 10% RPM
Fan Noise: 38.5 dBA (Max)
Fan Airflow: 98.0 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 360W
Material: Cu base + Alu fins + 6 heat pipes

CS-SP3-4UM95-PRO
Coolserver SP3 cooler, TDP: 380W

CS-SP3-4UM95-PRO

CPU Socket: AMD® SP3/TR4
Voltage: 12V
Dimensions: 118*103*124.5mm
Fan Speed: 2000-5000 ± 10% RPM
Fan Noise: 45.0 dBA (Max)
Fan Airflow: 128.0 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 380W
Material: Cu base + Alu fins + 6 heat pipes

CS-SP3-4UM97
Coolserver SP3 cooler, TDP: 380W

CS-SP3-4UM97

CPU Socket: AMD® SP3/TR4
Voltage: 12V
Dimensions: 126.7*102*155mm
Fan Speed: 1000-2200 ± 10% RPM
Fan Noise: 36.0 dBA (Max)
Fan Airflow: 72.68 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 380W
Material: Cu base + Alu fins + 5 heat pipes

CS-SP3-4UM95-PRO
Coolserver SP3 cooler, TDP: 400W

CS-SP3-4UM97 PRO

CPU Socket: AMD® SP3/TR4
Voltage: 12V
Dimensions: 125*100.4*153mm
Fan Speed: 1000-2200 ± 10% RPM
Fan Noise: 36.0 dBA (Max)
Fan Airflow: 72.68 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 400W
Material: Cu base + Alu fins + 5 heat pipes

CS-SP3-4UM98 PRO

CPU Socket: AMD® SP3/TR4
Voltage: 12V
Dimensions: 127.5*101.4*150mm
Fan Speed: 800-2100 ± 10% RPM
Fan Noise: 36.0 dBA (Max)
Fan Airflow: 72.68 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 420W
Material: Cu base + Alu fins + 6 heat pipes

CS-SP3-4UM99

CPU Socket: AMD® SP3/TR4
Voltage: 12V
Dimensions: 132*120*152.8mm
Fan Speed: 1000-2200 ± 10% RPM
Fan Noise: 36.0 dBA (Max)
Fan Airflow: 72.68 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 420W
Material: Cu base + Alu fins + 6 heat pipes

CS-SP3-4UM99 PRO

CPU Socket: AMD® SP3/TR4
Voltage: 12V
Dimensions: 137.9*122.9*152.8mm
Fan Speed: 800-2100 ± 10% RPM
Fan Noise: 36.0 dBA (Max)
Fan Airflow: 72.68 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 420W
Material: Cu base + Alu fins + 6 heat pipes

SP5 (LGA 6096)

CS-SP5-1US11-P
Coolserver SP5 Cooler, TDP: 255W

CS-SP5-1US11-P

CPU Socket: AMD® SP5
Passive cooler
Dimensions: 118mm*92.4mm*25mm
Fin thickness: 0.3mm
Fin spacing: 1.65mm
TDP: 255W
Material: Cu base + Alu fins

CS-SP5-2UF21(EVAC）
Coolserver SP5 Cooler, TDP: 550W

CS-SP5-2UF21(EVAC）

CPU Socket: AMD® SP5
Passive cooler
Dimensions:317mm*293mm*61.2mm
Fin thickness: 0.3mm
Fin spacing: 2.0mm
TDP: 550W
Material: Cu base + Alu fins + 8 heat pipes

CS-SP5-2US21-P
Coolserver SP5 Cooler, TDP: 395W

CS-SP5-2US21-P

CPU Socket: AMD® SP5
Passive cooler
Dimensions:118mm*92.4mm*64.5mm
Fin thickness: 0.4mm
Fin spacing: 2.0mm
TDP: 395W
Material: Cu base + Alu fins + 6 heat pipes

CS-SP5-2US22
Coolserver SP5 Cooler, TDP: 320W

CS-SP5-2US22

CPU Socket: AMD® SP5
Voltage: 12V
Dimensions:118mm*92.4mm*66.3mm
Fan Speed: 2600-8000 ± 10% RPM
Fan Noise: 52.5 dBA (Max)
Fan Airflow: 47.2 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 400W
Material: Cu base + Alu fins + 6 heat pipes

CS-SP5-2US87
Coolserver SP5 Cooler, TDP: 400W

CS-SP5-2US87

CPU Socket: AMD® SP5
Voltage: 12V
Dimensions:118mm*92.4mm*64.5mm
Fan Speed: 3000-11000 ± 10% RPM
Fan Noise: 58.5 dBA (Max)
Fan Airflow: 62.0 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 400W
Material: Cu base + Alu fins + 5 heat pipes

CS-SP5-4US42

CS-SP5-4US42

CPU Socket: AMD® SP5
Voltage: 12V
Dimensions:118mm*92.4mm*125mm
Fan Speed: 1900-3800 ± 10% RPM
Fan Noise: 44.0 dBA (Max)
Fan Airflow: 61.46 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 380W
Material: Cu base + Alu fins + 6 heat pipes

CS-SP5-4UM95 PRO

CS-SP5-4UM95 PRO

CPU Socket: AMD® SP5
Voltage: 12V
Dimensions:118mm*100mm*126mm
Fan Speed: 2000-5000 ± 10% RPM
Fan Noise: 45.0 dBA (Max)
Fan Airflow: 128.0 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 435W
Material: Cu base + Alu fins + 6 heat pipes

CS-SP5-4UM97

CS-SP5-4UM97

CPU Socket: AMD® SP5
Voltage: 12V
Dimensions:125mm*102.6mm*155mm
Fan Speed: 1000-2200 ± 10% RPM
Fan Noise: 36.0 dBA (Max)
Fan Airflow: 72.68 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 420W
Material: Cu base + Alu fins + 5 heat pipes

CS-SP5-4UM97 PRO

CS-SP5-4UM97 PRO

CPU Socket: AMD® SP5
Voltage: 12V
Dimensions:125mm*100.4mm*153mm
Fan Speed: 800-2100 ± 10% RPM
Fan Noise: 32.2dBA (Max)
Fan Airflow: 77.8 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 435W
Material: Cu base + Alu fins + 5 heat pipes

CS-SP5-4UM98

CS-SP5-4UM98

CPU Socket: AMD® SP5
Voltage: 12V
Dimensions:130mm*100mm*154mm
Fan Speed: 1000-2200 ± 10% RPM
Fan Noise: 36.0 dBA (Max)
Fan Airflow: 72.68 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 440W
Material: Cu base + Alu fins + 6 heat pipes

CS-SP5-4UM98 PRO

CPU Socket: AMD® SP5
Voltage: 12V
Dimensions:127.5mm*101.4mm*150mm
Fan Speed: 800-2100 ± 10% RPM
Fan Noise: 32.2 dBA (Max)
Fan Airflow: 77.8 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 445W
Material: Cu base + Alu fins + 6 heat pipes

CS-SP5-4UM99

CPU Socket: AMD® SP5
Voltage: 12V
Dimensions:134.5mm*120mm*153mm
Fan Speed: 1000-2200 ± 10% RPM
Fan Noise: 36.0 dBA (Max)
Fan Airflow: 72.68 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 455W
Material: Cu base + Alu fins + 6 heat pipes

SP6 (LGA 4844)

CS-SP6-1UT11-P

CS-SP6-1UT11-P

CPU Socket: AMD® SP6
Passive cooler
Dimensions: 118mm*78.9mm*26mm
Fin thickness: 0.3mm
Fin spacing: 1.65mm
TDP: 180W
Material: Cu base + Alu fins

CS-SP6-2UT21-P

CS-SP6-2UT21-P

CPU Socket: AMD® SP6
Passive cooler
Dimensions: 118mm*78.9mm*64mm
Fin thickness: 0.4mm
Fin spacing: 2.0mm
TDP: 240W
Material: Cu base + Alu fins + 4 heat pipes

CS-SP6-2UT22

CS-SP6-2UT22

CPU Socket: AMD® SP6
Voltage: 12V
Dimensions:115mm*78.9mm*66.3mm
Fan Speed: 2600-8000 ± 10% RPM
Fan Noise: 52.5 dBA (Max)
Fan Airflow: 47.2 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 320W
Material: Alu fins + 5 heat pipes

CS-SP6-2UM87

CS-SP6-2UM87

CPU Socket: AMD® SP6
Voltage: 12V
Dimensions:118mm*79mm*64.5mm
Fan Speed: 3000-11000 ± 10% RPM
Fan Noise: 58.5 dBA (Max)
Fan Airflow: 62.0 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 335W
Material: Cu base + Alu fins + 5 heat pipes

CS-SP6-4UT42

CS-SP6-4UT42

CPU Socket: AMD® SP6
Voltage: 12V
Dimensions:118.2mm*92.5mm*125.4mm
Fan Speed: 1900-3800 ± 10% RPM
Fan Noise: 44.0 dBA (Max)
Fan Airflow: 61.46 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 300W
Material: Cu base + Alu fins + 6 heat pipes

CS-SP6-4UM95 PRO

CS-SP6-4UM95 PRO

CPU Socket: AMD® SP6
Voltage: 12V
Dimensions:118mm*100mm*126mm
Fan Speed: 2000-5000 ± 10% RPM
Fan Noise: 45.0 dBA (Max)
Fan Airflow: 128.0 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 355W
Material: Cu base + Alu fins + 6 heat pipes

CS-SP6-2UM97

CS-SP6-2UM97

CPU Socket: AMD® SP6
Voltage: 12V
Dimensions:125mm*102.6mm*155mm
Fan Speed: 1000-2200 ± 10% RPM
Fan Noise: 36.0 dBA (Max)
Fan Airflow: 72.68 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 380W
Material: Cu base + Alu fins + 5 heat pipes

CS-SP6-4UM97 PRO

CS-SP6-4UM97 PRO

CPU Socket: AMD® SP6
Voltage: 12V
Dimensions:125mm*100.4mm*153mm
Fan Speed: 800-2100 ± 10% RPM
Fan Noise: 32.2 dBA (Max)
Fan Airflow: 77.8 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 400W
Material: Cu base + Alu fins + 5 heat pipes

CS-SP6-4UM98

CS-SP6-4UM98

CPU Socket: AMD® SP6
Voltage: 12V
Dimensions:130mm*103mm*154mm
Fan Speed: 1000-2200 ± 10% RPM
Fan Noise: 36.0 dBA (Max)
Fan Airflow: 72.68 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 390W
Material: Cu base + Alu fins + 6 heat pipes

CS-SP6-4UM98 PRO

CS-SP6-4UM98 PRO

CPU Socket: AMD® SP6
Voltage: 12V
Dimensions:127.5mm*101.4mm*150mm
Fan Speed: 800-2100 ± 10% RPM
Fan Noise: 32.2 dBA (Max)
Fan Airflow: 77.8 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 410W
Material: Cu base + Alu fins + 6 heat pipes

CS-SP6-4UM99

CPU Socket: AMD® SP6
Voltage: 12V
Dimensions:132mm*120mm*152.8mm
Fan Speed: 1000-2200 ± 10% RPM
Fan Noise: 36.0 dBA (Max)
Fan Airflow: 72.68 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 415W
Material: Cu base + Alu fins + 6 heat pipes

SP7

CS-SP7-1US11

CS-SP7-1US11

CPU Socket: AMD® SP7
Passive cooler
Dimensions: 118*101.5*25mm
Fin thickness: 0.3mm
Fin spacing: 1.65mm
TDP: 260W
Material: Cu base + Alu fins + 4 heat pipes

CS-SP7-2US21

CS-SP7-2US21

CPU Socket: AMD® SP7
Passive cooler
Dimensions: 118*101.5*64.5mm
Fin thickness: 0.4mm
Fin spacing: 2.0mm
TDP: 350W
Material: Cu base + Alu fins + 6 heat pipes

CS-SP7-2US22

CS-SP7-2US22

CPU Socket: AMD® SP7
Voltage: 12V
Dimensions: 118*101.5*66.3mm
Fan Speed: 2600-8000 ± 10% RPM
Fan Noise: 52.5 dBA (Max)
Fan Airflow: 47.2 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 380W
Material: Cu base + Alu fins + 6 heat pipes

CS-SP7-2US87

CS-SP7-2US87

CPU Socket: AMD® SP7
Voltage: 12V
Dimensions: 118*101.5*64.5mm
Fan Speed: 3000-11000 ± 10% RPM
Fan Noise: 58.5 dBA (Max)
Fan Airflow: 62.0 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 400W
Material: Cu base + Alu fins + 5 heat pipes

CS-SP7-4US42

CS-SP7-4US42

CPU Socket: AMD® SP7
Voltage: 12V
Dimensions: 118*101.5*125.7mm
Fan Speed: 1900-3800 ± 10% RPM
Fan Noise: 44.0 dBA (Max)
Fan Airflow: 61.46 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 400W
Material: Cu base + Alu fins + 6 heat pipes

CS-SP7-4UM95 PRO

CS-SP7-4UM95 PRO

CPU Socket: AMD® SP7
Voltage: 12V
Dimensions: 118*104*124.9mm
Fan Speed: 2000-5000 ± 10% RPM
Fan Noise: 45.0 dBA (Max)
Fan Airflow: 128.0 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 400W
Material: Cu base + Alu fins + 6 heat pipes

CS-SP7-4UM98

CS-SP7-4UM98

CPU Socket: AMD® SP7
Voltage: 12V
Dimensions: 133*105.3*154mm
Fan Speed: 1000-2200 ± 10% RPM
Fan Noise: 36.0 dBA (Max)
Fan Airflow: 72.68 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 400W
Material: Cu base + Alu fins + 6 heat pipes

CS-SP7-4UM98 PRO

CPU Socket: AMD® SP7
Voltage: 12V
Dimensions: 101.3*127.5*153mm
Fan Speed: 800-2100 ± 10% RPM
Fan Noise: 32.2 dBA (Max)
Fan Airflow: 77.8 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 420W
Material: Cu base + Alu fins + 6 heat pipes

CS-SP7-4UM99

CS-SP7-4UM99

CPU Socket: AMD® SP6
Voltage: 12V
Dimensions: 138.2*124*151mm
Fan Speed: 1000-2200 ± 10% RPM
Fan Noise: 36.0 dBA (Max)
Fan Airflow: 72.68 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 450W
Material: Cu base + Alu fins + 6 heat pipes

SP8

CS-SP8-1U S11

CPU Socket: AMD® SP8
Passive cooler
Dimensions: 118*82*25mm
Fin thickness: 0.3mm
Fin spacing: 1.65mm
TDP: 260W
Material: Cu base + Alu fins + 4 heat pipes

CS-SP8-2U S21

CPU Socket: AMD® SP8
Passive cooler
Dimensions: 118*82*64.5mm
Fin thickness: 0.4mm
Fin spacing: 2.0mm
TDP: 350W
Material: Cu base + Alu fins + 6 heat pipes

CS-SP8-2US22

CPU Socket: AMD® SP8
Passive cooler
Dimensions: 118*82*66.3mm
Fan Speed: 2600-8000 ± 10% RPM
Fan Noise: 52.5 dBA (Max)
Fan Airflow: 47.2 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 380W
Material: Cu base + Alu fins + 6 heat pipes

CS-SP8-4US42

CPU Socket: AMD® SP8
Passive cooler
Dimensions: 118*92.5*125.7mm
Fan Speed: 1900-3800 ± 10% RPM
Fan Noise: 44.0 dBA (Max)
Fan Airflow: 61.46 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 400W
Material: Cu base + Alu fins + 6 heat pipes

CS-SP8-4U M95

CPU Socket: AMD® SP8
Passive cooler
Dimensions: 118*104*125.4mm
Fan Speed: 1500-3800 ± 10% RPM
Fan Noise: 38.5 dBA (Max)
Fan Airflow: 98 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 380W
Material: Cu base + Alu fins + 6 heat pipes

CS-SP8-4U M95 PRO

CPU Socket: AMD® SP8
Passive cooler
Dimensions: 118*104*124.9mm
Fan Speed: 2000-5000 ± 10% RPM
Fan Noise: 45 dBA (Max)
Fan Airflow: 128 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 400W
Material: Cu base + Alu fins + 6 heat pipes

CS-SP8-4U M98 PRO

CPU Socket: AMD® SP8
Passive cooler
Dimensions: 118*127.5*149.9mm
Fan Speed: 800-2100 ± 10% RPM
Fan Noise: 32.2 dBA (Max)
Fan Airflow: 77.8 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 410W
Material: Cu base + Alu fins + 6 heat pipes

CS-SP8-4U M99 PRO

CPU Socket: AMD® SP8
Passive cooler
Dimensions: 137.9*120*150.7mm
Fan Speed: 800-2100 ± 10% RPM
Fan Noise: 32.2 dBA (Max)
Fan Airflow: 77.8 CFM (Max)
Fan Connector: 4-Pin PWM
Bearing Type: double ball
TDP: 450W
Material: Cu base + Alu fins + 6 heat pipes
