Fan / Accessories

Fan

6025

Fan size: 60mm*60mm*25mm
Fan voltage: 12V
Fan current: 0.5A
Fan air volume: 34.5 CFM
Fan air pressure: 16.2 mm/H₂O
Fan Speed: 2100-6800 RPM±10%
Bearing Type: double ball
Noise: 52.0 dB(A)
Fan interface: 4PIN PWM
MTBF: 70,000 hrs at 40°C,15-65% relative humidity

8015

Fan size: 79mm*77.5mm*15mm
Fan voltage: 12V
Fan current: 1.2A
Fan air volume: 21.35 CFM
Fan air pressure: 36 mm/H₂O
Fan Speed: 1500-6600 RPM±10%
Noise: 64.0 dB(A)
Bearing Type: double ball
Fan interface: 4PIN PWM
MTBF: 70,000 hrs at 40°C,15-65% relative humidity

12025

Fan size: 120mm*120mm*25mm
Fan voltage: 12V
Fan current: 0.22A
Fan air volume: 86 CFM
Fan air pressure: 4.8 mm/H₂O
Fan Speed: 1000-2200 RPM±10%
Noise: 32.0 dB(A)
Bearing Type: double ball
Fan interface: 4PIN PWM
MTBF: 70,000 hrs at 40°C,15-65% relative humidity

12028

Fan size: 120mm*120mm*28mm
Fan voltage: 12V
Fan current: 0.20A
Fan air volume: 72.68 CFM
Fan air pressure: 3.18 mm/H₂O
Fan Speed: 1000-2200 RPM±10%
Noise: 36.0 dB(A)
Bearing Type: double ball
Fan interface: 4PIN PWM
MTBF: 70,000 hrs at 40°C,15-65% relative humidity
