Intel CPU Series
LGA 1700/1851
CS-1700-1UV11-P
Vapor chamber
- CPU Socket: Intel® 1700/1851
- Passive cooler
- Dimensions: 90mm*90mm*25mm
- Fin thickness: 0.3mm
- Fin spacing: 1.7mm
- TDP: 135W
- Material: VC base + copper fins
CS-1700-1UV11A-P
Vapor chamber
- CPU Socket: Intel® 1700/1851
- Passive cooler
- Dimensions: 90mm*90mm*25.5mm
- Fin thickness: 0.25mm
- Fin spacing: 1.36mm
- TDP: 130W
- Material: VC base + Alu fins
CS-1700-1U1C-P
- CPU Socket: Intel® 1700/1851
- Passive cooler
- Dimensions: 88mm*88mm*25mm
- Fin thickness: 0.3mm
- Fin spacing: 2.1mm
- TDP: 95W
- Material: Cu base + copper fins
CS-1700-1U3C
- CPU Socket: Intel® 1700/1851
- Voltage: 12V
- Dimensions: 90mm*89mm*27mm
- Fan Speed: 1000-6000 ± 10% RPM
- Fan Noise: 56.0 dBA (Max)
- Fan Airflow: 18.0 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 115W
- Material: Cu base + copper fins
CS-1700-1UV12
Vapor chamber
- CPU Socket: Intel® 1700/1851
- Voltage: 12V
- Dimensions: 90mm*90mm*28mm
- Fan Speed: 1500-6600 ± 10% RPM
- Fan Noise: 64.0 dBA (Max)
- Fan Airflow: 21.35 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 125W
- Material: VC base + copper fins
CS-1700-2UR27-P
- CPU Socket: Intel® 1700/1851
- Passive cooler
- Dimensions: 90mm*90mm*65mm
- Fin thickness: 0.4mm
- Fin spacing: 2.0mm
- TDP: 220W
- Material: Cu base + Alu fins + 4 heat pipes
CS-1700-2UV15
Vapor chamber
- CPU Socket: Intel® 1700/1851
- Voltage: 12V
- Dimensions: 91mm*90mm*65.5mm
- Fan Speed: 2600-8000 ± 10% RPM
- Fan Noise: 52.5 dBA (Max)
- Fan Airflow: 47.2 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 160W
- Material: VC base + Alu fins + 2 heat pipes
CS-1700-2UR67
- CPU Socket: Intel® 1700/1851
- Voltage: 12V
- Dimensions: 88mm*90mm*67mm
- Fan Speed: 2600-8000 ± 10% RPM
- Fan Noise: 52.5 dBA (Max)
- Fan Airflow: 47.2 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 235W
- Material: Alu fins + 5 heat pipes
CS-1700-2UR63
- CPU Socket: Intel® 1700/1851
- Voltage: 12V
- Dimensions: 90mm*90mm*67mm
- Fan Speed: 2600-8000 ± 10% RPM
- Fan Noise: 52.5 dBA (Max)
- Fan Airflow: 47.2 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 160W
- Material: Alu fins + 4 heat pipes
CS-1700-2UR64
- CPU Socket: Intel® 1700/1851
- Voltage: 12V
- Dimensions: 90mm*90mm*67mm
- Fan Speed: 2100-6800 ± 10% RPM
- Fan Noise: 52.0 dBA (Max)
- Fan Airflow: 34.5CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 200W
- Material: Alu fins + 4 heat pipes
CS-1700-2UR65
- CPU Socket: Intel® 1700/1851
- Voltage: 12V
- Dimensions:90mm*90.5mm*67.7mm
- Fan Speed: 2600-8000 ± 10% RPM
- Fan Noise: 52.5 dBA (Max)
- Fan Airflow: 47.2 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 220W
- Material: Alu fins + 5 heat pipes
CS-1700-2UR67
- CPU Socket: Intel® 1700/1851
- Voltage: 12V
- Dimensions: 88mm*90mm*67mm
- Fan Speed: 2600-8000 ± 10% RPM
- Fan Noise: 52.5 dBA (Max)
- Fan Airflow: 47.2 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 235W
- Material: Alu fins + 5 heat pipes
CS-1700-4UR19
- CPU Socket: Intel® 1700/1851
- Voltage: 12V
- Dimensions:105mm*92.5mm*125.8mm
- Fan Speed: 1300-3800 ± 10% RPM
- Fan Noise: 40.0 dBA (Max)
- Fan Airflow: 61.46 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 215W
- Material: Cu Base + Alu fins + 5 heat pipes
CS-1700-4UR22
- CPU Socket: Intel® 1700/1851
- Voltage: 12V
- Dimensions:98.8mm*92.5mm*124.8mm
- Fan Speed: 1300-3800 ± 10% RPM
- Fan Noise: 36.74 dBA (Max)
- Fan Airflow: 42.64 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 215W
- Material: Alu fins + 5 heat pipes
CS-1700-4UR25
- CPU Socket: Intel® 1700/1851
- Voltage: 12V
- Dimensions: 120mm*108mm*155mm
- Fan Speed: 1000-2200 ± 10% RPM
- Fan Noise: 36.0 dBA (Max)
- Fan Airflow: 72.68 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 255W
- Material: Cu Base + Alu fins + 6 heat pipes
CS-1700-4UR26
- CPU Socket: Intel® 1700/1851
- Voltage: 12V
- Dimensions: 130mm*106mm*151mm
- Fan Speed: 1000-2200 ± 10% RPM
- Fan Noise: 36.0 dBA (Max)
- Fan Airflow: 72.68 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 280W
- Material: Cu Base + Alu fins + 6 heat pipes
CS-1700-4UR28
- CPU Socket: Intel® 1700/1851
- Voltage: 12V
- Dimensions: 110mm*96mm*125mm
- Fan Speed: 1600-6000 ± 10% RPM
- Fan Noise: 51.97 dBA (Max)
- Fan Airflow: 95.3 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 260W
- Material: Cu base + Alu fins + 6 heat pipes
CS-1700-4UR29
- CPU Socket: Intel® 1700/1851
- Voltage: 12V
- Dimensions: 100mm*96mm*125mm
- Fan Speed: 2000-5000 ± 10% RPM
- Fan Noise: 45.0 dBA (Max)
- Fan Airflow: 128 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 270W
- Material: Cu base + Alu fins + 6 heat pipes
CS-1700-4UR96
- CPU Socket: Intel® 1700/1851
- Voltage: 12V
- Dimensions:114mm*92.5mm*125.7mm
- Fan Speed: 1300-3800 ± 10% RPM
- Fan Noise: 40.0 dBA (Max)
- Fan Airflow: 61.46 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 245W
- Material: Cu Base + Alu fins + 6 heat pipes
LGA 115X/1200
CS-115X-1U1C-P
- CPU Socket: Intel® 115X
- Passive cooler
- Dimensions: 88mm*88mm*23mm
- Fin thickness: 0.35mm
- Fin spacing: 1.9mm
- TDP: 95W
- Material: Cu base + copper fins
CS-115X-1U1CA-P
- CPU Socket: Intel® 115X
- Passive cooler
- Dimensions: 90mm*90mm*27mm
- Fin thickness: 0.25mm
- Fin spacing: 1.36mm
- TDP: 95W
- Material: Cu base + Alu fins + 1 heat pipe
CS-115X-1U3C
- CPU Socket: Intel® 115X
- Voltage: 12V
- Dimensions: 83mm*83mm*28mm
- Fan Speed: 2000-5000 ± 10% RPM
- Fan Noise: 54.8 dBA (Max)
- Fan Airflow: 10.37 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 110W
- Material: Cu base + copper fins
CS-115X-1UV12
Vapor chamber
- CPU Socket: Intel® 115X
- Voltage: 12V
- Dimensions: 90mm*90mm*28mm
- Fan Speed: 1500-6600 ± 10% RPM
- Fan Noise: 64.0 dBA (Max)
- Fan Airflow: 21.35 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 180W
- Material: VC base + copper fins
CS-115X-2U3C
- CPU Socket: Intel® 115X
- Voltage: 12V
- Dimensions: 90mm*89mm*47mm
- Fan Speed: 1700-4300 ± 10% RPM
- Fan Noise: 37.0 dBA (Max)
- Fan Airflow:32.49 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 110W
- Material: Cu base + copper fins
CS-115X-2UV15
Vapor chamber
- CPU Socket: Intel® 115X
- Voltage: 12V
- Dimensions: 91mm*90mm*65.5mm
- Fan Speed: 2600-8000 ± 10% RPM
- Fan Noise: 52.50 dBA (Max)
- Fan Airflow: 47.2 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 200W
- Material: VC base + Alu fins + 2 heat pipes
CS-115X-2U6C
- CPU Socket: Intel® 115X
- Voltage: 12V
- Dimensions: 93mm*90mm*67mm
- Fan Speed: 2100-6800 ± 10% RPM
- Fan Noise: 52.0 dBA (Max)
- Fan Airflow: 34.5 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 135W
- Material: Cu base + cooper fins
CS-115X-2U6CA
- CPU Socket: Intel® 115X
- Voltage: 12V
- Dimensions: 93mm*90mm*67mm
- Fan Speed: 2100-6800 ± 10% RPM
- Fan Noise: 52.0 dBA (Max)
- Fan Airflow: 34.5 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 95W
- Material: Cu base + Alu fins
CS-115X-2UHP4
- CPU Socket: Intel® 115X
- Voltage: 12V
- Dimensions: 93mm*90mm*67mm
- Fan Speed: 2100-6800 ± 10% RPM
- Fan Noise: 52.0 dBA (Max)
- Fan Airflow: 34.5 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 120W
- Material: Alu fins + 4 heat pipes
CS-115X-2UR63
- CPU Socket: Intel® 115X
- Voltage: 12V
- Dimensions: 90mm*90mm*67mm
- Fan Speed: 2100-6800 ± 10% RPM
- Fan Noise: 52.0 dBA (Max)
- Fan Airflow: 34.5 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 150W
- Material: Alu fins + 4 heat pipes
CS-115X-2UR64
- CPU Socket: Intel® 115X
- Voltage: 12V
- Dimensions: 90mm*90mm*67mm
- Fan Speed: 2100-6800 ± 10% RPM
- Fan Noise: 52.0 dBA (Max)
- Fan Airflow: 34.5 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 180W
- Material: Alu fins + 4 heat pipes
CS-115X-2UR65
- CPU Socket: Intel® 115X
- Voltage: 12V
- Dimensions: 90mm*90.5mm*67.7mm
- Fan Speed: 2600-8000 ± 10% RPM
- Fan Noise: 52.5 dBA (Max)
- Fan Airflow: 47.2 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 180W
- Material: Alu fins + 5 heat pipes
CS-115X-2UR67
- CPU Socket: Intel® 115X
- Voltage: 12V
- Dimensions: 88mm*90mm*67mm
- Fan Speed: 2600-8000 ± 10% RPM
- Fan Noise: 52.5 dBA (Max)
- Fan Airflow: 47.2 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 180W
- Material: Alu fins + 5 heat pipes
CS-115X-4UR19
- CPU Socket: Intel® 115X
- Voltage: 12V
- Dimensions:105mm*92.5mm*125.8mm
- Fan Speed: 1900-3800 ± 10% RPM
- Fan Noise: 44.0 dBA (Max)
- Fan Airflow: 61.46 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 165W
- Material: Cu base + Alu fins + 5 heat pipes
CS-115X-4UR22
- CPU Socket: Intel® 115X
- Voltage: 12V
- Dimensions:98.8mm*92.5mm*124.8mm
- Fan Speed: 1900-3800 ± 10% RPM
- Fan Noise: 44.0 dBA (Max)
- Fan Airflow: 61.46 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 200W
- Material: Alu fins + 5 heat pipes
CS-115X-4UR28
- CPU Socket: Intel® 115X
- Voltage: 12V
- Dimensions: 110mm*96mm*125mm
- Fan Speed: 1600-6000 ± 10% RPM
- Fan Noise: 51.97 dBA (Max)
- Fan Airflow: 95.3 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 240W
- Material: Cu base + Alu fins + 6 heat pipes
LGA 2011 Narrow/Square
CS-2011-1U1C-NP
- CPU Socket: Intel® 2011
- Passive cooler
- Dimensions: 104mm*65mm*24mm
- Fin thickness: 0.4mm
- Fin spacing: 1.9mm
- TDP: 115W
- Material: Cu base + copper fins
CS-2011-1U1C-SP
Square
- CPU Socket: Intel® 2011
- Passive cooler
- Dimensions: 88mm*88mm*23mm
- Fin thickness: 0.35mm
- Fin spacing: 1.9mm
- TDP: 100W
- Material: Cu base + copper fins
CS-2011-1U3C-NP
- CPU Socket: Intel® 2011
- Voltage: 12V
- Dimensions: 104mm*74mm*28mm
- Fan Speed: 2000-5000 ± 10% RPM
- Fan Noise: 54.8 dBA (Max)
- Fan Airflow: 10.37 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 105W
- Material: Cu base + copper fins
CS-2011-1U3C-S
Square
- CPU Socket: Intel® 2011
- Voltage: 12V
- Dimensions: 88mm*88mm*28mm
- Fan Speed: 2000-5000 ± 10% RPM
- Fan Noise: 54.8 dBA (Max)
- Fan Airflow: 10.37 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 110W
- Material: Cu base + copper fins
CS-2011-2UR16-N
- CPU Socket: Intel® 2011
- Voltage: 12V
- Dimensions:104mm*80mm*64.5mm
- Fan Speed: 2100-6800 ± 10% RPM
- Fan Noise: 52.0 dBA (Max)
- Fan Airflow: 34.5CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 150W
- Material: Alu fins + 4 heat pipes
CS-2011-2U3CC-S
Square
- CPU Socket: Intel® 2011
- Voltage: 12V
- Dimensions: 90mm*90mm*48mm
- Fan Speed: 1700-4300 ± 10% RPM
- Fan Noise: 37.0 dBA (Max)
- Fan Airflow:32.49 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 95W
- Material: Cu base + copper fins
CS-2011-2UR63-N
- CPU Socket: Intel® 2011
- Voltage: 12V
- Dimensions:104mm*79.5mm*67mm
- Fan Speed: 2100-6800 ± 10% RPM
- Fan Noise: 52.0 dBA (Max)
- Fan Airflow: 34.5CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 180W
- Material: Alu fins + 4 heat pipes
CS-2011-2UR63-S
Square
- CPU Socket: Intel® 2011
- Voltage: 12V
- Dimensions:90mm*90mm*67mm
- Fan Speed: 2100-6800 ± 10% RPM
- Fan Noise: 52.0 dBA (Max)
- Fan Airflow: 34.5CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 180W
- Material: Alu fins + 4 heat pipes
CS-2011-4UR19-S
Square
- CPU Socket: Intel® 2011
- Voltage: 12V
- Dimensions:105mm*92.5mm*125.8mm
- Fan Speed: 1900-3800 ± 10% RPM
- Fan Noise: 44.0 dBA (Max)
- Fan Airflow: 61.46 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 220W
- Material: Cu base + Alu fins + 5 heat pipes
LGA 3647 Narrow/Square
CS-3647-1UR77-N
- CPU Socket: Intel® 3647
- Passive cooler
- Dimensions: 108mm*78mm*25.5mm
- Fin thickness: 0.3mm
- Fin spacing: 1.6mm
- TDP: 180W
- Material: Cu base + Alu fins + 4 heat pipes
CS-3647-1UR73-N
- CPU Socket: Intel® 3647
- Voltage: 12V
- Dimensions: 108mm*80mm*27.3mm
- Fan Speed: 1500-6600 ± 10% RPM
- Fan Noise: 64.0 dBA (Max)
- Fan Airflow: 21.35 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 180W
- Material: Cu base + copper fins + 3 heat pipes
CS-3647-2UR81-NP
- CPU Socket: Intel® 3647
- Passive cooler
- Dimensions: 108mm*78mm*64mm
- Fin thickness: 0.4mm
- Fin spacing: 2.04mm
- TDP: 205W
- Material: Cu base + Alu fins + 4 heat pipes
CS-3647-2UR82-N
- CPU Socket: Intel® 3647
- Voltage: 12V
- Dimensions: 108mm*78mm*64.5mm
- Fan Speed: 2100-6800 ± 10% RPM
- Fan Noise: 52.0 dBA (Max)
- Fan Airflow: 34.5 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 205W
- Material: Cu base + Alu fins + 3 heat pipes
CS-3647-2UR83-N
- CPU Socket: Intel® 3647
- Voltage: 12V
- Dimensions: 108mm*78mm*64.5mm
- Fan Speed: 2600-8000 ± 10% RPM
- Fan Noise: 52.5 dBA (Max)
- Fan Airflow: 47.2 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 225W
- Material: Cu base + Alu fins + 4 heat pipes
CS-3647-2U82-S
Square
- CPU Socket: Intel® 3647
- Voltage: 12V
- Dimensions: 91mm*88mm*64.5mm
- Fan Speed: 2100-6800 ± 10% RPM
- Fan Noise: 52.0 dBA (Max)
- Fan Airflow: 34.5 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 205W
- Material: Cu base + Alu fins + 4 heat pipes
CS-3647-4UR92-S
Square
- CPU Socket: Intel® 3647
- Voltage: 12V
- Dimensions:91mm*88mm*125.5mm
- Fan Speed: 1900-3800 ± 10% RPM
- Fan Noise: 44.0 dBA (Max)
- Fan Airflow: 61.46 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 240W
- Material: Cu base + Alu fins + 5 heat pipes
CS-3647-4UR91-N
- CPU Socket: Intel® 3647
- Voltage: 12V
- Dimensions:102mm*91mm*125.5mm
- Fan Speed: 1900-3800 ± 10% RPM
- Fan Noise: 44.0 dBA (Max)
- Fan Airflow: 61.46 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 255W
- Material: Cu base + Alu fins + 5 heat pipes
CS-3647-4UR96-N
- CPU Socket: Intel® 3647
- Voltage: 12V
- Dimensions:116.2mm*92.5mm*125.5mm
- Fan Speed: 1900-3800 ± 10% RPM
- Fan Noise: 44.0 dBA (Max)
- Fan Airflow: 61.46 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 265W
- Material: Cu base + Alu fins + 6 heat pipes
CS-3647-4UR97-S
Square
- CPU Socket: Intel® 3647
- Voltage: 12V
- Dimensions:126.7mm*102mm*155mm
- Fan Speed: 1000-2200 ± 10% RPM
- Fan Noise: 36.0 dBA (Max)
- Fan Airflow: 72.68 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 280W
- Material: Cu base + Alu fins + 5 heat pipes
CS-3647-4UR95-N
- CPU Socket: Intel® 3647
- Voltage: 12V
- Dimensions:120mm*102.6mm*155mm
- Fan Speed: 1000-2200 ± 10% RPM
- Fan Noise: 36.0 dBA (Max)
- Fan Airflow: 72.68 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 300W
- Material: Cu base + Alu fins + 5 heat pipes
LGA 4189
CS-4189-1UV71-P
Vapor chamber
- CPU Socket: Intel® 4189
- Passive cooler
- Dimensions: 113mm*78mm*25mm
- Fin thickness: 0.3mm
- Fin spacing: 1.5mm
- TDP: 180W
- Material: VC base + Alu fins
CS-4189-1UV72-P
Vapor chamber
- CPU Socket: Intel® 4189
- Passive cooler
- Dimensions: 113mm*78mm*25mm
- Fin thickness: 0.3mm
- Fin spacing: 1.5mm
- TDP: 200W
- Material: VC base + copper fins
CS-4189-1UV75
Vapor chamber
- CPU Socket: Intel® 4189
- Voltage: 12V
- Dimensions: 113mm*80mm*28mm
- Fan Speed: 1500-6600 ± 10% RPM
- Fan Noise: 64.0 dBA (Max)
- Fan Airflow: 21.35 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 200W
- Material: VC base + copper fins
CS-4189-1UM71-P
- CPU Socket: Intel® 4189
- Passive cooler
- Dimensions: 113mm*79mm*25mm
- Fin thickness: 0.3mm
- Fin spacing: 1.5mm
- TDP: 185W
- Material: Cu base + Alu fins + 4 heat pipes
CS-4189-2UM81-P
- CPU Socket: Intel® 4189
- Passive cooler
- Dimensions: 113mm*78mm*64.5mm
- Fin thickness: 0.35mm
- Fin spacing: 1.65mm
- TDP: 185W
- Material: Cu base + Alu fins + 5 heat pipes
CS-4189-2UM82
- CPU Socket: Intel® 4189
- Voltage: 12V
- Dimensions:113mm*80mm*66.3mm
- Fan Speed: 2600-8000 ± 10% RPM
- Fan Noise: 52.5 dBA (Max)
- Fan Airflow: 47.2 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 320W
- Material: Alu fins + 5 heat pipes
CS-4189-2UM83
- CPU Socket: Intel® 4189
- Voltage: 12V
- Dimensions:113mm*78mm*64.5mm
- Fan Speed: 2600-8000 ± 10% RPM
- Fan Noise: 52.5 dBA (Max)
- Fan Airflow: 47.2 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 285W
- Material: Cu base + Alu fins + 4 heat pipes
CS-4189-2UM87
- CPU Socket: Intel® 4189
- Voltage: 12V
- Dimensions:113mm*79mm*64.5mm
- Fan Speed: 3000-11000 ± 10% RPM
- Fan Noise: 58.5 dBA (Max)
- Fan Airflow: 62.0 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 385W
- Material:Cu base + Alu fins + 5 heat pipes
CS-4189-4UM95 PRO
- CPU Socket: Intel® 4189
- Voltage: 12V
- Dimensions:113mm*100mm*125m
- Fan Speed: 2000-5000 ± 10% RPM
- Fan Noise: 45.0 dBA (Max)
- Fan Airflow: 128.0 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 385W
- Material: Cu base + Alu fins + 6 heat pipes
CS-4189-4UM96
- CPU Socket: Intel® 4677
- Voltage: 12V
- Dimensions:116.7mm*92.5mm*125.5mm
- Fan Speed: 1300-3800 ± 10% RPM
- Fan Noise: 36.74 dBA (Max)
- Fan Airflow: 42.64 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 350W
- Material: Cu base + Alu fins + 6 heat pipes
CS-4189-4UM97 PRO
- CPU Socket: Intel® 4189
- Voltage: 12V
- Dimensions:125mm*100.4mm*153mm
- Fan Speed: 1000-2200 ± 10% RPM
- Fan Noise: 36.0 dBA (Max)
- Fan Airflow: 72.68 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 410W
- Material: Cu base + Alu fins + 5 heat pipes
CS-4189-4UM98 PRO
- CPU Socket: Intel® 4189
- Voltage: 12V
- Dimensions:128mm*101.4mm*150mm
- Fan Speed: 1000-2200 ± 10% RPM
- Fan Noise: 36.0 dBA (Max)
- Fan Airflow: 72.68 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 425W
- Material: Cu base + Alu fins + 6 heat pipes
LGA 4677/4710
CS-4677-1UM71-P
- CPU Socket: Intel® 4677
- Passive cooler
- Dimensions: 118mm*78mm*25.3mm
- Fin thickness: 0.3mm
- Fin spacing: 1.5mm
- TDP: 185W
- Material: Cu base + Alu fins + 4 heat pipes
CS-4677-2UM81-P
- CPU Socket: Intel® 4677
- Passive cooler
- Dimensions: 118mm*78mm*63mm
- Fin thickness: 0.35mm
- Fin spacing: 1.65mm
- TDP: 320W
- Material: Cu base + Alu fins + 5 heat pipes
CS-4677-2UM82
- CPU Socket: Intel® 4677
- Voltage: 12V
- Dimensions: 118mm*78mm*66mm
- Fan Speed: 2100-8000 ± 10% RPM
- Fan Noise: 54.34 dBA (Max)
- Fan Airflow: 34.74 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 320W
- Material: Cu base + Alu fins + 5 heat pipes
CS-4677-2UM83
- CPU Socket: Intel® 4677
- Voltage: 12V
- Dimensions:118mm*78mm*64.5mm
- Fan Speed: 2100-8000 ± 10% RPM
- Fan Noise: 54.34 dBA (Max)
- Fan Airflow: 34.74 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 285W
- Material: Cu base + Alu fins + 4 heat pipes
CS-4677-2UM87
- CPU Socket: Intel® 4677
- Voltage: 12V
- Dimensions: 118mm*79mm*64.5mm
- Fan Speed: 3000-11000 ± 10% RPM
- Fan Noise: 52.5 dBA (Max)
- Fan Airflow: 47.2 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 385W
- Material: Cu base + Alu fins + 5 heat pipes
CS-4677-2UF76
- CPU Socket: Intel® 4677
- Passive cooler
- Dimensions: 133mm*78mm*64mm
- Fin thickness: 0.3mm
- Fin spacing: 1.5mm
- TDP: 250W
- Material: Cu base + Alu fins + 5 heat pipes
CS-4677-4UM95 PRO
- CPU Socket: Intel® 4677
- Voltage: 12V
- Dimensions:118mm*100mm*125mm
- Fan Speed: 2000-5000 ± 10% RPM
- Fan Noise: 45.0 dBA (Max)
- Fan Airflow: 128.0 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 400W
- Material: Cu base + Alu fins + 5 heat pipes
CS-4677-4UM96
- CPU Socket: Intel® 4677
- Voltage: 12V
- Dimensions:119.2mm*92.5mm*125.5mm
- Fan Speed: 1300-3800 ± 10% RPM
- Fan Noise: 36.74 dBA (Max)
- Fan Airflow: 42.64 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 350W
- Material: Cu base + Alu fins + 6 heat pipes
CS-4677-4UM97
- CPU Socket: Intel® 4677
- Voltage: 12V
- Dimensions:125mm*102.6mm*155mm
- Fan Speed: 1000-2200 ± 10% RPM
- Fan Noise: 36.0 dBA (Max)
- Fan Airflow: 72.68 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 395W
- Material:Cu base+Alu fins+5 heat pipes
CS-4677-4UM97 PRO
- CPU Socket: Intel® 4677
- Voltage: 12V
- Dimensions:125mm*100.4mm*153mm
- Fan Speed: 1000-2200 ± 10% RPM
- Fan Noise: 36.0 dBA (Max)
- Fan Airflow: 72.68 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 410W
- Material: Cu base + Alu fins + 5 heat pipes
CS-4677-4UM98 PRO
- CPU Socket: Intel® 4677
- Voltage: 12V
- Dimensions:127.5mm*101.4mm*150mm
- Fan Speed: 1000-2200 ± 10% RPM
- Fan Noise: 36.0 dBA (Max)
- Fan Airflow: 72.68 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 425W
- Material: Cu base + Alu fins + 6 heat pipes
CS-4677-4UM99
- CPU Socket: Intel® 4677
- Voltage: 12V
- Dimensions:132mm*120mm*152.8mm
- Fan Speed: 1000-2200 ± 10% RPM
- Fan Noise: 36.0 dBA (Max)
- Fan Airflow: 72.68 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 425W
- Material: Cu base + Alu fins + 6 heat pipes
LGA 7529
CS-7529-1UA11P
- CPU Socket: Intel® 7529
- Passive cooler
- Dimensions: 126.8mm*97.8mm*25mm
- Fin thickness: 0.3mm
- Fin spacing: 1.5mm
- TDP: 320W
- Material: Cu base + Alu fins + 5 heat pipes
CS-7529-2UA21P
- CPU Socket: Intel® 7529
- Passive cooler
- Dimensions: 127mm*98mm*65.5mm
- Fin thickness: 0.4mm
- Fin spacing: 2.1mm
- TDP: 450W
- Material:Cu base+Alu fins + 8 heat pipes
CS-7529-4UM95
- CPU Socket: Intel® 7529
- Voltage: 12V
- Dimensions:126.8mm*103mm*121.3mm
- Fan Speed: 1000-2200 ± 10% RPM
- Fan Noise: 32.0 dBA (Max)
- Fan Airflow: 86.0 CFM (Max)
- Fan Connector: 4-Pin PWM
- Bearing Type: double ball
- TDP: 500W
- Material:Cu base+Alu fins + 6 heat pipes
